Automatic Corrugated Board Feeder Feeding Flatbed Auto Die Cutting Machine

This machine realizes the automation of paper feeding, die cutting and paper feeding process. Use the "human-machine interface" to display the machine's working speed, the number of processed sheets, the total running time and the working status of the machine; realize the dynamic monitoring of the input point, output point and various faults of the programmable controller, so that the troubleshooting and operation of the convenient. (Optional) The function of the preset technical device can realize that the air pump stops at a preset number of times and automatically marks; the electronic cam composed of the encoder and the programmable controller is accurate and reliable, and the adjustment is convenient. The frequency converter is used to control the speed of the main motor, with stable operation, low noise and energy saving. This machine also has automatic fault detection (including detection of double sheets, empty sheets, paper accumulation, falling paper, etc.), non-stop sampling function, high die-cutting pressure, high registration accuracy, multiple sensors and safety protection equipment. Ensure the normal operation of the machine and the safety of personnel.

The main drive system of this machine is equipped with a pneumatic clutch, and the main sprocket shaft is equipped with a torque limiter (safety clutch) to avoid injury and damage to the operator and equipment due to emergencies, and to ensure personal safety and equipment safety.

The whole machine is equipped with multiple safety protection devices. Once someone touches or enters the area, the alarm device will automatically alarm and the equipment is in a shutdown state.

Parameter

Feeder feeding unit

lAdopt four-suction and four-feeding powerful feeder to keep stable and smooth.

lThe inclined paper feeding table is more suitable for the conveying and positioning of high speed paper feeding;

lNon-stop paper lifting platform device; double-piece control device;

lSide positioning adopts pull & push dual-purpose side gauge device, which is easy to switch according to paper selection;

lmported high-quality blown/inhalation dual-purpose vacuum pump;

Die Cutting unit

lThe clutch has low noise and excellent braking performance

lThere are two sets of single-acting pre-regulatory bodies in the pre-regulatory department.

lHigh-strength aluminum alloy gripper with high rigidity, light weight and low inertia in high speed operation accurately and smoothly deliver paper.

Packaging & Delivery
Packaging Details:
We usually packed this machine covered by plastic film.
Delivery Detail:
Within 30-45 days after we got the deposit.
