Full Automatic Corrugated Paperboard Flute Laminating Machine Flute Laminator Machine

This machine is a quick sticker for printing cardboard and corrugated paper.The whole machine is designed for the tissue paper from Feeder paper,the end of the paper from the front edge of the composition of the automatic feeding part of the paper,and paste paste,press the delivery part of the composition.Suitable for cardboard and corrugated,so that cardboard more eye-catching,beautiful,high strength,is the production of high-quality cardboard of the new equipment.Widely used in food,alcohol,household appliances,light industrial products packing.

MESSAGE

PRODUCT RECOMMENDATION

Product Description

1.The vacuum suction-type feeding system can lead the paper accurately into the machine; Cycle stacking planes could stack the next batch paper well in a state of non-stop working , more efficient.

2.Bottom sheet use suction auto feeding, automatic tracking according to the face paper's speed.

3.New concept front gauge location, position high accuracy, bottom sheet never pull ahead.

4.Machine uses touch-screen/PLC/servo motor control system, circuit system is stable and could display the failure alarm automatically.

5. Automatic gluing, and the glue can be used circulatory, avoid glue waste.

6. Roller design scientifically, avoid glue fly out when the speed is high.

7. Pressure rollers adopt one side adjustment, convenient and fast.

8. Rocker controls wash roller's fluctuation, easy cleaning.

9. Counter designs scientifically, easy recording the amount you have been worked.

model	HF-A1300	HF-A1500	HF-A1600
max.size of cover face	1300*1100	1450*1100	1600*1250
min.size of cover face	400*400	400*400	400*400
economic speed	0-100pcs/min	0-100pcs/min	0-100pcs/min
lamintor precision	±1.5	±1.5	±1.5
power	10	12	12
size	1000020002400mm	1000021502400mm	1000022502400mm
weight	5T	6T	6T

Details of machine

	Top feeding unit Put the paperboard on the flat plate, this unit automatically up to the designated location, feeder deliver the paperboard by vacuum absorption.
Bottom feeding unit This unit adopted the unique electrical transmission structure, ensure the high speed of sheet conveying and accuracy and not deflect. The transmitting belt has strong adaptability of the Alice of corrugated paper.
	Positioning unit The use of multiple sets of photoelectric senor at bottom sheets relative position, control top sheets on both sides of the servo motor to do independent compensation action, so that accurate positioning of top paper and the bottom paper.
Gluing unit: Using stainless steel glue roller, never rust, after grinding the amount of glue keeps in the minimum to ensure uniform glue, lower roller is use water roller clean.
